Product Description
The MVnex‑12 (MSAMV001) is a flagship medium‑voltage air‑insulated switchgear developed by Schneider Electric and supplied by Gaobo Switchgear Manufacturer. It is rated for 12kV / 24kV, 50/60Hz AC systems, for receiving, distributing and protecting electrical energy in substations, factories, buildings and infrastructure projects.
Constructed with high‑strength galvanized steel plates and epoxy powder coating, the cabinet is metal‑enclosed, metal‑clad and divided into separate compartments (busbar, circuit breaker, cable, low‑voltage) for maximum safety. The withdrawable circuit breaker truck enables easy installation, inspection and replacement without shutting down the entire system.
At its core is the Schneider HVX solid‑sealed pole vacuum circuit breaker, which delivers high breaking capacity, low maintenance and long service life (up to 30 years). The switchgear features five‑prevention interlocking to eliminate misoperation risks and meets IP4X (enclosure) / IP2X (compartments) protection against dust and foreign objects.
Optional smart monitoring enables online condition tracking, fault diagnosis and predictive maintenance, reducing operational costs and unplanned downtime. Compact and modular, MVnex‑12 saves space while offering flexible primary wiring schemes for diverse project requirements.
Technical Specification
| Item | Parameter |
|---|---|
| Product Model | MSAMV001 / MVnex‑12 |
| Rated Voltage | 12kV (up to 24kV) |
| Rated Frequency | 50Hz / 60Hz |
| Rated Current (Busbar/Circuit Breaker) | 630A – 4000A |
| Rated Short‑Time Withstand Current (4s) | 25kA / 31.5kA / 40kA |
| Rated Peak Withstand Current | 63kA / 80kA / 100kA |
| Power Frequency Withstand Voltage (1min) | 42kV (12kV) / 65kV (24kV) |
| Lightning Impulse Withstand Voltage | 75kV (12kV) / 125kV (24kV) |
| Protection Grade | Enclosure IP4X, Compartment IP2X |
| Main Circuit Breaker | Schneider HVX solid‑sealed vacuum type |
| Structure | Indoor, metal‑clad, mid‑mount, withdrawable |
| Compliance | IEC 60298, IEC 60694, GB 3906‑2020 |
| Manufacturer | Schneider Electric (supplied by Gaobo Switchgear) |
Key Features:
Genuine Schneider MVnex‑12 (MSAMV001) quality & reliability施耐德电气
AIS (Air Insulated) design, up to 24kV rated voltage
Withdrawable mid‑mount structure, easy maintenance & expansion
HVX solid‑sealed vacuum circuit breaker, high endurance
IP4X / IP2X protection, safe for harsh indoor environments
Smart monitoring ready, IoT‑enabled O&M
IEC 60298 / GB 3906 compliant, global certification
Applications
Urban & rural MV substations (12kV / 24kV)
Industrial plants, factories & manufacturing facilities
Commercial buildings, shopping malls & high‑rises
Renewable energy (solar/wind) power stations
Infrastructure: airports, railways, ports & data centers
